4890030 Potter Strobe Light with Wall Mount and Horn 24VDC - Red

• Model Number: HS-24WR
• Item Number: 4890030
• 24VDC units have field selectable candela options of 15, 30, 60, 75, & 110
• Super-Slide Bracket - Ease of Supervision Testing
• Checkmate® - Instant Voltage Verification
• Synchronize strobe and/or horn with AVSM Control Module
• Prewire entire system, install mounting bracket, then install signals
• Documented lower installation and operating costs

Features

• 24VDC units have field selectable candela options of 15, 30, 60, 75, & 110
• Super-Slide® Bracket - Ease of Supervision Testing
• Checkmate® - Instant Voltage Verification
• Synchronize strobe and/or horn with AVSM Control Module
• Prewire entire system, install mounting bracket, then install signals
• Documented lower installation and operating costs
• Input terminals accept 12 to 18 AWG
• Switch selection for high or low dBA
• Switch for chime, whoop, mechanical and 2400Hz tone
• Tamperproof re-entrant style grill
• Switch for continuous or temporal 3 tone (not available on whoop tone)
• Surface mount with the AVBB (Surface Mount Back Box)
• Silence audible while visual appliance will remain flashing (for use in accepted jurisdictions)
• Faceplate available in red or off-white
  Operating Temperature
• 32°F to 120°F (0°C to 49°C). The HS and S Series are not listed for outdoor use.
  Unit Dimensions
• 5” (12.7 cm) high x 4.5” (11.43 cm) wide x 2.5” (6.35 cm) deep

4890030 Datasheet
